808nm Diode Laser Machine for Permanent Hair Removal
Working Principle
The 808nm Diode Laser Hair Removal Machine operates on the principle of selective photothermolysis. The 808nm wavelength laser is optimally absorbed by melanin in hair follicles while minimizing damage to surrounding skin tissue. The absorbed light energy converts to heat, raising the follicle temperature to levels that permanently disable hair growth without harming the epidermis.
This advanced system features long pulse-width 808nm laser technology that penetrates deep into hair follicles. The selective absorption targets melanin in hair shafts and follicles, precisely destroying them while the integrated cooling system protects surrounding skin for safe, comfortable treatments.
Technical Specifications
| Description |
808nm diode laser hair removal machine |
| Voltage |
110V-130V / 60Hz, 220V-240V / 50Hz |
| Machine Screen |
8 inches touch screen |
| Laser Type |
Diode laser |
| Wavelength |
808nm - 810nm |
| Output Power |
Microchannel: 3 chips-450W, 4 chips-600W, 6 chips-900W
Macro channel: 6 bars-360W, 8 bars-480W, 12 bars-720W
|
| Energy Density |
0-120J/cm² |
| Pulse Width Range |
1-400ms |
| Frequency |
1-10Hz |
| Spot Size |
15*15mm² (Optional: 31*25mm²) |
| Cooling System |
Semiconductor + intelligent cooling + water + wind + gel |
| Skin Cooling |
TEC+Sapphire |
| Machine Size |
650*450*730mm |
Technical Advantages
- Optimal Wavelength: 808nm is the most effective wavelength for melanin absorption in hair follicles
- Sapphire Cooling: Laser head features sapphire contact for skin cooling and protection
- Smart Operation: Automatic parameter adjustment based on hair thickness and treatment area
- Precision Targeting: Laser activates only upon skin contact for accurate treatment
- Advanced Safety: Multi-layer cooling system prevents skin damage
Treatment Areas
Effective for permanent hair removal on all body areas including face, lips, beard, underarms, arms, legs, chest, back, and bikini line. Achieves international standard hair reduction results.
Packaging & Shipping
Packaging: Standard export wooden case or aluminum case
Shipping Methods: By sea / air / express (DHL, FEDEX, TNT, EMS)
Payment Terms: T/T (Bank transfer), Western Union
We select the most reliable shipping methods with tracking provided upon dispatch.
Frequently Asked Questions
1. Do you provide warranty?
Yes, we offer 12 months warranty on the host machine and 3 months free replacement for handles, treatment heads, and parts.
2. What after-sales support do you provide?
Our professional technical support team is available via phone, webcam, and online chat (Skype, Facebook) for immediate assistance.
3. What certifications does the machine have?
All machines are CE certified, ensuring quality and safety compliance. We maintain strict quality control standards.
4. Is training provided for machine operation?
Yes, we provide comprehensive user manuals, instructional videos, and 24/7 online support for all operational questions.
5. Why choose our products?
With 12 years of experience in beauty equipment manufacturing, we offer:
- Competitive pricing from our powerful factory
- Strong R&D capabilities
- 1-year warranty with 24/7 support
- CE certified products
- Custom OEM/ODM services available
